一、產品簡介

手推路面兩用型車底2視角監控拍照系統是一款多功能型新型產品，它可以同時顯示車輛底盤的2個方向的超高清圖像，擴展了全車底的視野，既可以手推移動，也可擺放于路面，兩種檢測模式都可以對車底違禁物或車況進行安全檢查，可以很便捷地布防在要求對出入口、通道口的車輛進行檢查。通過對被檢車輛底部圖像進行采集，以確定車輛底部是否加裝違禁物品或夾帶管控物品、藏匿涉罪人員或車輛進行了非法改裝或存在安全行駛的隱患。該產品具有2個方向的超高清實時監控、抓圖、錄像及回放及車牌識別與車輛進出記錄等功能，很方便將圖像存儲到PAD或小移動工控機存儲卡上做備份也可以通過WIFI或5G等無線方式將前方車底檢查圖像傳輸?shù)胶蠓街笓]平臺集中監管，可以讓現場安檢人員快速便捷地進行安全檢查，也同時能讓后方指揮人員能遠程決策指揮，大大提高了安檢工作效率，增強了安全管控的科技水平。

Hand-push road dual-use vehicle chassis 2-view monitoring and photo system is a multi-functional new product, which can simultaneously display the vehicle chassis of the two directions of the ultra-high-definition image, expanding the vision of the entire vehicle chassis, both hand-push mobile, can also be placed on the road, both inspection modes can be under the vehicle prohibited substances or vehicle conditions for security checks, can be very convenient arming in the requirements of the entrances and exits, access points to the vehicle Inspection. The image of the bottom of the inspected vehicle is captured to determine whether the bottom of the vehicle is retrofitted with prohibited items or entrapped with controlled items, hiding people involved in crime or the vehicle has been illegally modified or there are hidden dangers to safe driving. The product has two directions of ultra-high-definition real-time monitoring, capture, video and playback and license plate recognition and vehicle access records and other functions, it is very convenient to store the image to the PAD or a small mobile industrial computer memory card for backup can also be through WIFI or 5G and other wireless ways to the front of the vehicle chassis inspection images transmitted to the rear of the centralized supervision of the command platform, which can allow on-site security personnel to carry out quick and convenient security inspections At the same time, it also allows the rear commanders to make decisions remotely, which greatly improves the efficiency of the security check and enhances the scientific and technological level of security control.

二、產品特點

1、采用10寸或配置更強的PAD顯示與處理程序信息，或配置15寸彩色顯示器配置微型工控機來運行車底監控拍照系統軟件及存儲安檢信息，軟件顯示可以進行多國語言設置。

2、2個朝不同方向的超高清數字攝像機，多方向、無死視角、多畫面去觀看車輛底盤，安全檢查結果更清晰明了。

3、車底檢查儀配置車輛自動檢測模塊，可以自動檢測來車并自動對車底補光。也可在光線不充足的情況下，自動給各攝像機補光，讓車底檢查更清晰。同時補光亮度可以調節。

4、各次對車輛的檢查結果可查詢，信息包括車牌號碼、來車日期時間、受檢時的拍照與錄像等信息。檢查結果可反復觀看，并保存留檔。可本機存儲也可以云端上傳、遠程監管與回查。

1. The product features a 10-inch PAD or a more powerful configuration for displaying and processing program information, or a 15-inch color display with a mini industrial computer for running the vehicle chassis surveillance camera system software and storing security check information. The software display can be set in multiple languages.

2. The product features 2 ultra-HD digital cameras facing different directions, providing a multi-directional, no blind angle view of the vehicle chassis, making inspection results clearer.

3. The system is equipped with a vehicle automatic detection module, which can automatically detect incoming vehicles and automatically supplement light to the chassis. It can also automatically supplement light to each camera in low-light conditions, making the chassis clearer. The brightness of the supplemental lighting can be adjusted as well.

4.The inspection results of each vehicle can be queried, including information such as license plate number, date and time of arrival, and photos and videos taken during the inspection. The inspection results can be reviewed repeatedly and stored as records. They can be stored locally on the device or uploaded to the cloud for remote supervision and retrieval.

三、產品技術參數

1、顯示器、工作主機 Display、Host

2、攝像頭Camera

鏡頭：水平視場角 180°,垂直視場角 100°。

本儀器設有4個補光源 COB LED補光燈,采用智能自動感應式補光。高亮度12V LED燈補光，在光線不充足的情況下，可以給攝像頭補光，使之觀看事物更清晰。補光源亮度可以調節。

工作電壓：DC12V （可充電）

推桿連桿長度： 1.3米

攝像頭底座裝置高度：9.5cm

工作溫度： -10℃ - +50℃（℃）

Lens: Horizontal field of view 180°, vertical field of view 100°.

This instrument is equipped with 4 fill light sources COB LED fill light, using intelligent automatic induction fill light. High-brightness 12V LED light can provide fill light for the camera in low-light conditions, making it clearer to observe objects. The brightness of the fill light source can be adjusted.

Working Voltage：DC12V （Rechargeable）

Length of the push rod ：1.3m

Height of the camera base device：9.5cm

Working temperature： -10℃ - +50℃（℃）
